LCE500 5 W/m·K One Component High Thermal Conductivity Silicone Gel

Specification:
Thermal Conductivity:5.0±0.3 W/m·K
Thermal Impedance:0.033 ℃·in²/W
Extrusion Rate:≥40 g/min
BLT:≤1000 μm
Operating Temperature:-40~150 ℃
Introduction:
LCE500 silicone heat transfer gel offers 5 W/m·K thermal conductivity, electrical insulation, and low-pressure gap filling. Ready to use without mixing.
  • Product introduction
  • Technical Parameters
  • Product Application
  • Product Characteristics

LCE500 High Thermal Conductivity Silicone Gel | 5 W/m·K

LCE500 is a single-component, high thermal conductivity silicone gel designed for efficient thermal management in high-power electronic devices. With a thermal conductivity of 5 W/m·K, it facilitates rapid heat transfer from heat-generating components to heat sinks or enclosures.


Its soft, paste-like consistency allows it to conform to gaps and provide effective thermal contact under low pressure. This heat transfer gel requires no mixing and is ready to use, simplifying material preparation and application. Good thermal stability and excellent electrical insulation make LCE500 suitable for applications requiring both thermal conduction and gap filling, supporting efficient cooling and long-term, stable device operation.

Test Items

Unit

LCE500

Test Standard

Appearance

-

Gray

Visual

Density

g/cm3

3.44±0.2

ASTM D792

Extrusion Rate

g/min

≥40

φ2.54mm/90psi

BLT

μm

≤80

-

Dielectric Strength

KV/mm

≥7

ASTM D149

Volume Resistivity

Ω·cm

≥1×1013

ASTM D257

Weight Loss

%

≤0.2

150℃240H

Thermal Conductivity

W/m·K

5.0±0.3

ISO 22007-2

Thermal Conductivity

W/m·K

5.0±0.3

ASTM D5470(Three-Thickness Fit)

Thermal Impedance

℃·in²/W

0.033

ASTM D5470(0.1mm )

Thermal Impedance

℃·cm²/W

0.213

ASTM D5470(0.1mm )

Operating Temperature

℃

-40~150

-

Specific Heat Capacity

J/(g/K)

0.784

ASTM E1269


Features and Advantages


5 W/m·K thermal conductivity: Supports efficient heat transfer in high-power electronic applications.
Excellent electrical insulation: Provides thermal conduction while maintaining electrical insulation between components.
Soft, conformable consistency: Fills gaps between electronic components and heat sinks or enclosures under low pressure.
Single-component convenience: Ready to use without mixing, simplifying handling and application.
Stable thermal performance: Maintains stable performance across high and low temperatures for long-term reliability.

Material characteristics: Non-volatile, non-corrosive, environmentally friendly, and non-toxic.



Typical Applications


Electronic components and LED lighting: Transfers heat from integrated circuits (ICs), central processing units (CPUs), graphics processing units (GPUs), and LED lighting components to heat sinks.
Power electronics: Provides thermal conduction and gap filling for power modules and power semiconductors.
Communications and computing equipment: Supports cooling in communication base stations, 5G devices, servers, and other electronic equipment with high heat output.

Solar photovoltaic modules: Provides thermal conduction in solar photovoltaic applications.


LCE500 for Your Thermal Management Requirements

For buyers evaluating a one component thermal gel supplier, LCE500 combines a specified thermal conductivity of 5 W/m·K with electrical insulation, low-pressure conformability, and ready-to-use application. These characteristics provide a practical basis for material selection in electronic cooling and gap-filling applications.


Test Item
Unit LCE500 Test Methods
Color
- Gray
Visually
Specific Gravity
g/cc
3.44 ASTM D792
Extrusion Rate
g/min
≥20
φ2.54mm 90psi
Thickness After Compression
mm
0.2
-
Weight Loss
% ≤0.2
@150℃240H
Breakdown Voltage
KV/mm
≥7
ASTM D149
Volume Resistivity
Ω·cm
1×1013
ASTM D257
Continuous Use Temp
℃
-40~150
-
Thermal Conductivity
W/m·K
5.0 ISO 22007-2
Thermal impedance
℃·in2 /W
0.033
ASTM D5470
Wireless electronic equipment
Communication electronic hardware equipment
Automotive electronic application equipment
Chassis or related heat dissipation module
Host or small office network equipment
Microprocessors, memory chips and graphics processors
High thermal conductivity, low thermal resistance, good wettability
No settlement, no flow, can fill any uneven gap
Soft, no stress, can be compressed to 0.1 mm thin
The design and application are convenient, and the automatic dispensing can adjust the size of any thickness
