2 W/m·K Thermal Silicone Cloth Electrically Insulating Thermal Pad Sil-Pads

Specification:
LCV200S Thermally Conductive Silicone Fiberglass Sheet
Thermal conductivity:2.0±0.2 W/m·K
Thickness:0.25±0.03 mm
Breakdown Voltage:≥6 KV
Thermal Impedance:0.254 ℃·in²/W
Operating Temperature:-50~200℃
Custom Sizes & Die Cutting Supported
Introduction:
The LCV200S thermal silicone cloth is a fabric-like product made from silicone and fiberglass using a specialized manufacturing process.
LCV200S silicone fiberglass sheet offers 2.0 W/(m·K) nominal thermal conductivity and ≥6 kV dielectric breakdown voltage. Custom die cutting available.
  • Product introduction
  • Technical Parameters
  • Product Application
  • Product Characteristics

LCV200S Thermally Conductive Silicone Fiberglass Sheet

LCV200S is a fiberglass-reinforced silicone thermal interface sheet designed to transfer heat from electronic components to a heat sink or metal enclosure while providing electrical insulation between the mating surfaces. Its 0.25 mm nominal thickness suits assemblies with limited mounting clearance.


LCV200S silicone fiberglass sheet offers 2.0 W/(m·K) nominal thermal conductivity and ≥6 kV dielectric breakdown voltage. Custom die cutting available.


Technical Specifications


Test Items

Unit

LCV200S

Test Standard

Appearance

-

Pink

Visual

Thickness

mm

0.25±0.03

ASTM D374/374M

Hardness

Shore A

85±5

ISO 48-4

Density

g/cm³

2.9±0.1

ASTM D792

Breaking Force

N/25mm

≥100

ASTM D5035

Breakdown Voltage

KV

≥6

ASTM D149

Volume Resistivity

Ω·cm

≥1×10¹⁴

ASTM D257

Dielectric Constant

1MHz

3.0~3.5

ASTM D150

Thermal Conductivity

W/m·K

2.0±0.2

ASTM D5470

Thermal Impedance

℃·in²/W

0.254

ASTM D5470 (40psi)

Thermal Impedance

℃·cm²/W

1.640

ASTM D5470 (40psi)

Flammability

Grade

V-0

UL94

Operating Temperature

℃

-50~200

-

Key Features


Fiberglass reinforcement adds mechanical strength and helps the sheet resist tearing and abrasion during handling.
Non-tacky surfaces on both sides make the sheet easy to position and remove during assembly.
Resistance to weathering and aging makes the material suitable for long-term use in electronic assemblies.


Typical Applications


Computing and storage — Thermal interfaces between chips, processors, or storage devices and their heat sinks or enclosures.
Telecom and networking — Heat transfer from electronic components to heat sinks or housings in base stations and routers.
Automotive electronics — Thermal interfaces for heat-generating components in electronic control units (ECUs) and battery management systems (BMS).
Power electronics — Electrically insulating thermal interfaces between power modules and heat sinks.


Custom Sizes and Die Cutting

LCV200S is available in custom sheet sizes and die-cut shapes. When specifying a part, match the sheet dimensions to the contact area and check the available mounting gap against the thickness tolerance.


Request a quote with your required dimensions or die-cut drawing.

Test Items

Unit

LCV200S

Test Standard

Appearance

-

Pink

Visual

Thickness

mm

0.25±0.03

ASTM D374/374M

Hardness

Shore A

85±5

ISO 48-4

Density

g/cm³

2.9±0.1

ASTM D792

Breaking Force

N/25mm

≥100

ASTM D5035

Breakdown Voltage

KV

≥6

ASTM D149

Volume Resistivity

Ω·cm

≥1×10¹⁴

ASTM D257

Dielectric Constant

1MHz

3.0~3.5

ASTM D150

Thermal Conductivity

W/m·K

2.0±0.2

ASTM D5470

Thermal Impedance

℃·in²/W

0.254

ASTM D5470 (40psi)

Thermal Impedance

℃·cm²/W

1.640

ASTM D5470 (40psi)

Flammability

Grade

V-0

UL94

Operating Temperature

℃

-50~200

-

Typical Applications

· Thermal interface between chips, processors, storage devices, and heat sinks or enclosures

· Equipment requiring long-term stable cooling, such as base stations and routers

· Thermal interface in automotive electronic control units (ECUs) and battery management systems (BMS)

· Thermal management between power modules and heat sinks


Features and Advantages

· Excellent thermal conductivity and high electrical insulation

· High mechanical strength, wear-resistant, and tear-resistant

· Non-sticky on both sides, making it easy to handle and remove

· Exceptional weather and aging resistance, suitable for long-term use
